Bypass Odorizers
Description
MRR bypass odorizers use pipeline differential pressure to deliver odorant — no wicks, no external power, no moving parts in the gas stream. Five reservoir sizes from 6 to 250 gallons let you size the unit to the refill interval you want rather than to the pipeline, so a station on a modest feed can run a full year between deliveries. Every unit ships on stainless secondary containment with leveling feet, sits at grade without burying, and is National Board Registered with a CRN for service in the United States and Canada.
The odorizer takes 10" WC of differential pressure across a constricting valve or orifice plate, with no injection pump, no electrical service, and no wick to foul, saturate, or replace on a schedule. Stainless steel secondary containment ships under every unit, sized in excess of 10% of the reservoir volume, with leveling feet for placement on prepared grade — no excavation or below-grade vault. A magnetic level float is standard, with battery-operated radar available and able to feed Watchtower™ remote monitoring so refills are scheduled against actual consumption. Every reservoir is National Board Registered with a CRN, rated to 1,000 psig from −20°F to 150°F.
Renewable natural gas, CNG, LNG, and distribution gas. Transmission stations, distribution feeds, RNG interconnects, and temporary or seasonal service.
